SKLN Series Counterflow Cooler
SKLN Series Counterflow Cooler

SKLN Series Counterflow Cooler


Model: SKLN Series

Capacity: 2-25t/h

Certification: CE & SGS & ISO

Application: Cooling of feed pellets and wood pellets

Product Description

SKLN Series Counterflow Cooler Details

SKLN Series Counterflow Cooler
Henan Richi Machinery SKLN Series Counterflow Cooler, advanced theory of counterflow cooling, SKLN Series Counterflow Cooler widely applied in feed processing industry for cooling of all kinds of pellet materials.

Features

1. Adopt counter-flow cooling principle,pellet cooled fully and equally, smooth discharge, adjustable discharge flow and speed.

2. The equipment has access door in the front, the side and top cover have viewing windows for easy observation and inspection.

3. Pressure reduced board at discharging, improve the work load, reduce distortion, extend the life of the part.

4. The octagonal section of the cooling bin removes the cooling dead angle and is conducive to the full cooling of the material ,The pellet temperature after cooling is not higher room temperature +3-5 degree.

5. Air-enclosed feeder is adopted for feeding so as to avoid the air crossing at the feeding inlet, resulting in good cooling effect.

6. With special side valve discharging mechanism, balanced and reliable operation of side valve discharging mechanism,discharging feed fluently.

7. The new rotary spreader ensures that the material is fully uniform and thoroughly cooled, and can significantly reduce the crushing rate. The distribution range is adjustable, and the power consumption is small.

Parameter

Model SKLN11*11 SKLN14*14 SKLN17*17 SKLN20*20 SKLN24*24
Capacity(t/h) 1.5-2 3-5 5-8 9-12 13-18
Power(kw) 0.75 0.75 1.1 2.05 2.05
