SFSP Fine-Grinding Hammer Mill
SFSP Fine-Grinding Hammer Mill

SFSP Fine-Grinding Hammer Mill


Model: SFSP Series

Capacity: 3-12T/H

Certification: CE & SGS & ISO

Application: Suitable for corn, soybean, sorghum, wheat, beans, grain grinding

Product Description

Henan RICHI MACHINERY SFSP-series fine grain hammer mill is suitable for corn, soybean, sorghum, wheat, beans, grain grinding, Especially suitable for the pulverization of baby pig, fish feed, poultry and livestock Feed. It's widly used in animal feed processing, brewing, chemical and biological industry.Grain crushing machine, feed crusher for sale factory price is attractive.In addition, The machine structure is simple, fastening durable, safe, reliable with easy installation and simple operation.

SFSP Fine-Grinding Hammer Mill Details

SFSP Fine-Grinding Hammer Mill
After feeding into the machine through the upper feeder, the pre-grinding material enters the crushing chamber from right or left through the leading plate. It is then crushed by the high-rotating hammer and screen abrasion, and finally released from the outlet of the base against the centrifugation force and air flow.

Features

1.Advanced teardrop-shaped crushing chamber design, reasonable structure of the secondary crushing, output increase by 25% compared to other models

2.Movable operating door and linkage sieve press structure, more convenient for operation and maintenance.

3.High-precision dynamic balance detecting rotor, little vibration, low noise.

4.Patented ventilating from shaft end system, output of small aperture material increase by more than 25%.

5.Widened grinding surface, fully optimized hammer arrangement, wonderful performance in micro grinding.

6.Using the new-type adjustable sieve pressure plate, adjustable back gauge and tuning technique, to destroy the material circul ation layer.

7.Equipped with safety interlocking device for safety.

8.Forward and reverse work of rotor, longer service life of hammer.

Parameter

Model SFSP56*40a SFSP56*40b SFSP66*60a SFSP66*60b SFSP66*80a SFSP66*80b SFSP66*100 SFSP138*30E SFSP138*40E
Power 30kw 37kw 55kw 75kw 90kw 110kw 132kw 110/132kw 132/160kw
Capacity 3-5T/H 4-6T/H 5-8T/H 6-9T/H 8-10T/H 10-13T/H 12-16T/H 15-20T/H 18-25T/H
Speed 2980r/min 2980r/min 2980r/min 2980r/min 2980r/min 2980r/min 2980r/min 1440r/min 1440r/min
